EnglishHT No: HT8120012
Date: 2019-11-08 Hits: 1 From: Zhejiang Hangtai automotive Components Co.,Ltd
| HT No： | HT8120012 |
| PULLEY： | |
| HUB： | |
| COIL： | |
| Connector： | |
| Diameter： | ￠105/￠100 |
| Belt Groove Type： | 8-PK |
| Bearing Size： | 35×52×12 |
| Hub Axlehole： | M10×1.25 |
| Rated Voltage： | |
| Compressor No/Model/year： | NipponDenso 7SEU17C/Benz W220 |
| Compressor O.E.M： | JPB00183/447180-8382 |
